Forklift Alternators and Starters
Forklift Starters and Alternators - The starter motor these days is typically either a series-parallel wound direct current electric motor that has a starter solenoid, that is similar to a relay mounted on it, or it can be a permanent-magnet composition. Once current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion which is located on the driveshaft and meshes the pinion with the starter ring gear that is found on the flywheel of the engine.
The solenoid closes the high-current contacts for the starter motor, that begins to turn. When the engine starts, the key operated switch is opened and a spring within the solenoid assembly pulls the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This allows the pinion to transmit drive in only a single direction. Drive is transmitted in this particular manner through the pinion to the flywheel ring gear. The pinion continuous to be engaged, for instance for the reason that the driver fails to release the key when the engine starts or if there is a short and the solenoid remains engaged. This actually causes the pinion to spin independently of its driveshaft.
The actions mentioned above will prevent the engine from driving the starter. This vital step prevents the starter from spinning really fast that it could fly apart. Unless modifications were done, the sprag clutch arrangement will preclude the use of the starter as a generator if it was utilized in the hybrid scheme mentioned prior. Typically a regular starter motor is meant for intermittent utilization that will preclude it being utilized as a generator.
The electrical components are made in order to work for approximately 30 seconds in order to prevent overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical parts are meant to save cost and weight. This is really the reason most owner's instruction manuals used for vehicles recommend the operator to stop for at least ten seconds after each and every ten or fifteen seconds of cranking the engine, when trying to start an engine which does not turn over instantly.
The overrunning-clutch pinion was introduced onto the marked in the early 1960's. Prior to the 1960's, a Bendix drive was used. This drive system works on a helically cut driveshaft that has a starter drive pinion placed on it. When the starter motor starts turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear allows the pinion to surpass the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.
During the 1930s, an intermediate development between the Bendix drive was made. The overrunning-clutch design which was developed and launched during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism together with a set of flyweights in the body of the drive unit. This was better since the average Bendix drive utilized to disengage from the ring once the engine fired, although it did not stay functioning.
Once the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, for instance it is backdriven by the running engine, and afterward the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, hence unwanted starter disengagement could be avoided prior to a successful engine start.
